Summary

It is rather easy to write a Verilog description that simulates fine, but produces cryptic error messages during the implementation (synthesis) phase. This document lists common problems and provides troubleshooting tips to resolve them (the links are simply bookmarks on this web page):

Multiple outputs driving a common net

Description

Multiple circuit outputs (gates or flip-flops) are tied together. This is not acceptable from an electrical standpoint.

Symptoms

Synthesis error message: “Net nnn has multiple drivers”

Cause

The same output signal name appears in more than one ‘always’ block

Troubleshooting

Search for the net named in the error message, and identify all the ‘always’ blocks where the name appears

Solution

Ensure that the output signal is contained within a single ‘always’ block

Comments

This problem is symptomatic of a sequential programming mindset. In order to break this mindset, focus your attention exclusively on a single device (a counter, for example), and write one ‘always’ block that describes the entire behavior of the counter (its behavior on asynchronous reset, and its normal behavior).

Inferred latch

Description

A latch (similar to a flip-flop, except it is level-triggered instead of edge-triggered) has been placed at the output of what is intended to be a purely combinational circuit.

Symptoms

Synthesis warning message: “Inferred latch…”

Cause

Combinational logic that does not fully specify the output behavior for all possible input combinations

Troubleshooting

First look for all combinational circuit ‘always’ blocks (those that do not have edge qualifiers). Inside these blocks look for ‘if’ statements that do not have an ‘else’, and ‘case’ statements that do not have a ‘default’.

Solution

Fix the ‘if’ or ‘case’ statement, or use technique of first setting all outputs to a nominal value before the conditional statements.

Comments

Inserting unintended memory devices in your design can cause operational problems in hardware, and will also cause problems in the implementation step.

Ignored synthesis warning messages

Description

You see one or more warnings during synthesis step, but ignore them and proceed to implementation

Symptoms

Yellow warnings appear in synthesis, followed by red error messages in implementation

Cause

Synthesis warnings mean that something is not correct. The problem may not be severe enough to be called an “error” that stops synthesis, but it effectively is an error for you because your design will not implement properly.

Troubleshooting

Same procedure as 'Solution' next

Solution

Start with first synthesis warning and solve that problem first. Often many (or all) successive warnings stem from the first cited problem. If you still have warnings, or possibly a totally new set of warnings, still tackle the first warning first.

Comments

The only synthesis warnings that can be safely ignored are those that you understand completely. For example, if you have intentionally connected an output pin to an input pin, you will see a warning about a “feed-through net”.

Synthesis tool removes portions of your design

Description

The synthesis tool always optimizes your design, and will eliminate any apparently unused portions of your circuit.

Symptoms

Synthesis warning message about “unreachable code” (as in an ‘if-else’ statement with a conditional test that is always false) or “unlinked cell,” or “removing pads.” Implementation error message saying named nets in UCF file are not found in your design.

Cause

If the synthesis tool concludes that some part of your circuit is useless (for example, its output does not connect to an external port and does not get used by any other internal device), then the tool removes the circuit and backtracks to remove any previous circuits that are only associated with the useless circuit. Eventually this can cause input ports to get removed as well.

Troubleshooting

Same procedure as 'Solution' next

Solution

Focus your attention on the named files and devices in the synthesis warning messages. Look for device outputs that do not connect to anything, or that connect to circuits that do nothing.

Comments

This is one of the more challenging problems to resolve!

Mixed edge-sensitive and level-sensitive signals in ‘always’ block sensitivity list

Description

Your ‘always’ block begins with something like: ‘always @ (posedge FirstSignal or SecondSignal)’

Symptoms

Synthesis tools will generate specific warning

Cause

If your circuit is supposed to be sequential, then you must use an edge qualifier (posedge or negedge) on both signals in the sensitivity list

Troubleshooting



Solution



Comments

The faulty ‘always’ block will simulate just fine, but it won’t synthesize.

Failure to name all inputs in sensitivity list for a combinational circuit

Description

Combinational circuits described by an ‘always’ block must list all inputs in the sensitivity list

Symptoms

Simulation will show a circuit output that is apparently unresponsive to one or more of the inputs. Synthesis will generate a warning about an “untested input”.

Cause

Simulator does not update an output unless the input is included in the sensitivity list; it effectively is blind to changes in that input.

Troubleshooting

Look at all signals on the right-hand side of all assignments in the ‘always’ block, and look for signal names that do not show up in the sensitivity list.

Solution

Ensure that every signal is included in the sensitivity list.

Comments
