Wideband FM Signals

There are four FM (Frequency Modulation) sounds to study. First listen to each of them without knowing how they differ.

sound.png sound.png sound.png sound.png

Each one of these FM signals is synthesized from the same basic formula: a sine-wave in the argument of a cosine function is used to "modulate" the frequency at the rate fm.

x(t) = A cos( 2π*fc*t + Df*cos(2π*fm*t) )

However, the fundamental idea of instantaneous frequency breaks down in this case because the chirp rate gets too high.

Let's look at the sounds in the time-frequency domain to see how the spectrum changes with increasing chirp rate.


chirpcov.png Home
